Automotive

Automotive Connectors > Terminal > Automotive

KN WP FEMALE TERMINAL

Part Number :: ST731516-4

Series :: SSD SERIES

첨부파일

2D PDF

기술 문의 품질 문의 구매 문의

General Feature

Series: SSD SERIES

Material Type: Phosphor Bronze

Dimensions: 1.8*14.9*0.64

Physical Feature

Plating: Ag/Ni

Sealed: YES

Tab Thickness(mm): 0.6

Primary Locking Type: HSG Lance

Mating Wire Seal: MG685540

Mating Tab Width(in): .050

Electrical Feature

Wire Range: AESSXF 0.3-0.5

Insulation Range: 1.4-1.7

Terminal Transmits(A): 5

Contact Resistance: 5mΩ MAX
